Electrical Conductivity Aerospace Wiring Solutions Monel 400 Wires

Place of Origin China
Brand Name DLX
Model Number Monel 400
Minimum Order Quantity 5
Price $30-$50
Packaging Details Spool package with Carton box, Coil package with polybag for monel 400 wire
Payment Terms L/C, T/T, Western Union, MoneyGram
Supply Ability 300 tons per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

WeChat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Delivery Time 7-50 Days Material Nickel Copper
Nickel(Min) 63% Curie Temperature 21-49℃
Density 8.05g/cm3 Application Anti-corrosion
Condition Hard / Soft Sureface Bright,Oxided
Melting Point 1288-1343℃ Name Monel 400 Wire

Aerospace Monel 400 Wires


Bright Monel 400 Wires


Aerospace Wiring Monel Alloy

Leave a Message
Product Description

Electrical Conductivity Aerospace Wiring Solutions Monel 400 Wires 0

Electrical Conductivity Aerospace Wiring Solutions Monel 400 Wires
Electrical Conductivity Aerospace Wiring Solutions Monel 400 Wires 1

  • Monel Series

This alloy can be mechanically processed using traditional iron-based material processing methods. High speed engine uses water coolant during overtime. The material shrinks during processing, and attention should be paid to ensuring dimensional accuracy with machining shrinkage allowance. Monel 400 has good welding performance and can use TIG and MIG methods. Monel body or EniCu-7 welding wire and electrode can be used; Or manual arc welding and submerged arc welding; Can be welded with carbon steel and low alloy steel.


  • Chemical Properties of Monel 400

Ni Cu Al Ti C Mn Fe S Si
63.0-70.0 27-33 2.30-3.15 0.35-0.85 0.25 max 1.5 max 2.0 max 0.01 max 0.50 max

  • Application

Monel 400 is a nickel-copper alloy known for its excellent corrosion resistance and high strength, performing admirably in various extreme environments. Wire made from Monel 400 finds wide applications in several fields, including:

1. Marine Engineering: Monel 400 wire is commonly used in the manufacturing of marine engineering equipment such as seawater desalination units, seawater pumps, and offshore oil pipelines, highly favored for its resistance to seawater corrosion.

2. Chemical Industry: Due to its corrosion resistance to various chemicals, Monel 400 wire is widely employed in the chemical industry for manufacturing chemical reactors, piping for acidic environments, and chemical equipment.

3. Aerospace Industry: Monel 400 wire is also utilized in the aerospace sector for fabricating components of aircraft and spacecraft, including engine parts, structural brackets, and hydraulic systems.

4. Marine Vessels: In the marine vessel sector, Monel 400 wire finds extensive use in the manufacturing of ship equipment and components such as hull structures, marine valves, and pipe fittings, to withstand corrosion from seawater and the marine environment.

5. Chemical Processing: Monel 400 wire is also commonly used in chemical processing and fine chemical industries for manufacturing corrosion-resistant equipment and piping systems, including chlorine processing units and petroleum processing equipment.

Electrical Conductivity Aerospace Wiring Solutions Monel 400 Wires 2

  • Mechanical Properties

    Typical Room Temperature Tensile Properties of Annealed Material

    Product Form Condition Tensile (ksi) .2% Yield (ksi) Elongation % Hardness
    Rod & Bar Hot-Finished/Aged 140-190 100-150 30-20 27-38 HRC
    Rod & Bar Hot Finished/Annealed 90-110 40-60 45-25 75-90 HRB
    Rod & Bar Hot Finished/Annealed/Aged 130-165 85-120 35-20 24-35 HRC
    Rod & Bar Cold-Drawn/Aged 135-185 95-160 30-15 25-41 HRC
    Rod & Bar Cold-Drawn/Annealed/Aged 130-190 85-120 30-20 24-35 HRC
    Plate ot-Finished/Aged 140-180 100-135 30-20 27-37 HRC
    Sheet Cold-Rolled/Annealed 90-105 40-65 45-25 85 HRB Max

    Electrical Conductivity Aerospace Wiring Solutions Monel 400 Wires 3Electrical Conductivity Aerospace Wiring Solutions Monel 400 Wires 4
