High Strength Monel K500 Tube Corrosion Resistant Nickel Alloy Pipe

Product Details

Place of Origin: China

Brand Name: DLX

Certification: CE,ROHS

Model Number: Monel K500

Payment & Shipping Terms

Minimum Order Quantity: 5

Packaging Details: Spool package with Carton box, Coil package with polybag

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price
Contact Now
Specifications
Highlight:

Corrosion Resistant Monel K500 Pipe

,

Monel K500 Nickel Alloy Pipe

,

Nickel Alloy Monel K500 Tube

Material:
Nickel Copper
Nickel(Min):
63%
Curie Temperature:
21-49℃
Density:
8.05g/cm3
Application:
Anti-corrosion
Condition:
Hard / Soft
Sureface:
Bright,Oxided
Delivery Time:
7-50 Days
Melting Point:
1288-1343℃
Name:
Monel K500 Tube
Material:
Nickel Copper
Nickel(Min):
63%
Curie Temperature:
21-49℃
Density:
8.05g/cm3
Application:
Anti-corrosion
Condition:
Hard / Soft
Sureface:
Bright,Oxided
Delivery Time:
7-50 Days
Melting Point:
1288-1343℃
Name:
Monel K500 Tube
Description
High Strength Monel K500 Tube Corrosion Resistant Nickel Alloy Pipe

High Strength Monel K500 Tube Corrosion Resistant Nickel Alloy Pipe 0

Monel K500 tube Corrosion Resistant Alloys nickel alloy pipe

What material is monelk500?

   Monel K500 is a high-strength, corrosion-resistant nickel copper alloy material. It is composed of about 65% nickel and about 30% copper, while containing small amounts of elements such as aluminum, iron, carbon, manganese, and titanium. The Monel K500 has excellent corrosion resistance, especially in corrosive media such as seawater, sulfuric acid, and hydrochloric acid. In addition, the Monel K500 also has good wear resistance, high temperature resistance, and fatigue resistance, making it widely used in marine engineering, chemical equipment, aerospace and other fields.

High Strength Monel K500 Tube Corrosion Resistant Nickel Alloy Pipe 1




  • Chemical Properties of Monel K500

Ni Cu Al Ti C Mn Fe S Si

63

Max

27-33 2.3-3.15 0.35-0.85 0.25 max 1.5 max 2.0 max 0.01 max 0.50 max


  • Application

. Sour-gas service applications
. Oil and gas production safety lifts and valves
. Oil-well tools and instruments like drill collars
. Oil well industry
. Doctor blades and scrapers
. Chains, cables, springs, valve trim, fasteners for marine service
. Pump shafts and impellers in marine service




  • ,Mechanical Properties

    Typical Room Temperature Tensile Properties of Annealed Material

    Product Form Condition Tensile (ksi) .2% Yield (ksi) Elongation % Hardness
    Rod & Bar Hot-Finished/Aged 140-190 100-150 30-20 27-38 HRC
    Rod & Bar Hot Finished/Annealed 90-110 40-60 45-25 75-90 HRB
    Rod & Bar Hot Finished/Annealed/Aged 130-165 85-120 35-20 24-35 HRC
    Rod & Bar Cold-Drawn/Aged 135-185 95-160 30-15 25-41 HRC
    Rod & Bar Cold-Drawn/Annealed/Aged 130-190 85-120 30-20 24-35 HRC
    Plate ot-Finished/Aged 140-180 100-135 30-20 27-37 HRC
    Sheet Cold-Rolled/Annealed 90-105 40-65 45-25 85 HRB Max
