Corrosion Resistance Super Alloy ASTM B127 UNS N04400 Monel 400 Strip

Product Details

Place of Origin: China

Brand Name: DLX

Model Number: Monel 400 strip

Payment & Shipping Terms

Minimum Order Quantity: 5

Packaging Details: Spool package with Carton box, Coil package with polybag for Monel 400 strip

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price
Contact Now
Specifications
Highlight:

UNS N04400 Monel 400 Strip

,

ASTM B127 Monel 400 Strip

,

Corrosion Resistance Monel 400 Strip

Material:
Nickel Copper
Nickel(Min):
63%
Curie Temperature:
21-49℃
Density:
8.05g/cm3
Application:
Anti-corrosion
Condition:
Hard / Soft
Sureface:
Bright,Oxided
Delivery Time:
7-50 Days
Melting Point:
1288-1343℃
Name:
Monel 400 Strip
Material:
Nickel Copper
Nickel(Min):
63%
Curie Temperature:
21-49℃
Density:
8.05g/cm3
Application:
Anti-corrosion
Condition:
Hard / Soft
Sureface:
Bright,Oxided
Delivery Time:
7-50 Days
Melting Point:
1288-1343℃
Name:
Monel 400 Strip
Description
Corrosion Resistance Super Alloy ASTM B127 UNS N04400 Monel 400 Strip

Corrosion Resistance super alloy ASTM B127 UNS N04400 Monel 400 Strip


  • Monel Series

Monel 400 is a solid-solution alloy that can be hardened only by cold working. It has high strength and toughness over a wide temperature range and excellent resistance to many corrosive environments.
Alloy 400 is widely used in many fields, especially marine and chemical processing. Typical applications are valves and pumps; pump and propeller shafts; marine fixtures and fasteners; electrical and electronic components; springs; chemical processing equipment; gasoline and fresh water tanks; crude petroleum stills, process vessels and piping; boiler feedwater heaters and other heat exchangers; and deaerating heaters



Monel 400 Characteristics

1; Resistant to seawater and steam at high temperatures

2; Excellent resistance to rapidly flowing brackish water or seawater

3; Excellent resistance to stress corrosion cracking in most freshwaters

4; Particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated

5; Offers some resistance to hydrochloric and sulfuric acids at modest temperatures and concentrations, but is seldom the material of choice for these acids

6; Excellent resistance to neutral and alkaline salt

7; Resistance to chloride induced stress corrosion cracking

8; Good mechanical properties from sub-zero temperatures up to 1020° F

9; High resistance to alkalis

Monel 400 Applications

1; Marine engineering

2; Chemical and hydrocarbon processing equipment

3; Gasoline and freshwater tanks

4; Crude petroleum stills

5; De-aerating heaters

6; Boiler feed water heaters and other heat exchangers

7; Valves, pumps, shafts, fittings, and fasteners

8; Industrial heat exchangers

9; Chlorinated solvents

10; Crude oil distillation towers




  • Chemical Properties of Monel 400

Ni Cu C Mn Fe S Si
63.0-70.0 28-34 0.3 max

2

max

2.5 max 0.024 max 0.50 max


  • Application

. Sour-gas service applications
. Oil and gas production safety lifts and valves
. Oil-well tools and instruments like drill collars
. Oil well industry
. Doctor blades and scrapers
. Chains, cables, springs, valve trim, fasteners for marine service
. Pump shafts and impellers in marine service




  • ,Mechanical Properties

    Typical Room Temperature Tensile Properties of Annealed Material

    Product Form Condition Tensile (ksi) .2% Yield (ksi) Elongation % Hardness
    Rod & Bar Hot-Finished/Aged 140-190 100-150 30-20 27-38 HRC
    Rod & Bar Hot Finished/Annealed 90-110 40-60 45-25 75-90 HRB
    Rod & Bar Hot Finished/Annealed/Aged 130-165 85-120 35-20 24-35 HRC
    Rod & Bar Cold-Drawn/Aged 135-185 95-160 30-15 25-41 HRC
    Rod & Bar Cold-Drawn/Annealed/Aged 130-190 85-120 30-20 24-35 HRC
    Plate ot-Finished/Aged 140-180 100-135 30-20 27-37 HRC
    Sheet Cold-Rolled/Annealed 90-105 40-65 45-25 85 HRB Max



    Corrosion Resistance Super Alloy ASTM B127 UNS N04400 Monel 400 Strip 0Corrosion Resistance Super Alloy ASTM B127 UNS N04400 Monel 400 Strip 1
