Product Details
Place of Origin: China
Brand Name: DLX
Certification: CE,ROHS
Model Number: incoloy 800H
Payment & Shipping Terms
Minimum Order Quantity: 10
Packaging Details: wooden case, woven polybag
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Material: |
Ni Fe Cr |
Nickel(Min): |
30% |
Coefficient Of Expansion: |
14.4 μm/m °C (20 – 100°C) |
Specific Heat: |
460 J/kg•°C |
Density: |
7.94 G/cm3 |
Curie Temperature: |
-115°C |
Sureface: |
Bright,Oxided |
Delivery Time: |
7-50 Days |
Thermal Conductivity: |
11.5 W/m-K |
Melting Point: |
1385°C |
Elongation: |
30 % |
Material: |
Ni Fe Cr |
Nickel(Min): |
30% |
Coefficient Of Expansion: |
14.4 μm/m °C (20 – 100°C) |
Specific Heat: |
460 J/kg•°C |
Density: |
7.94 G/cm3 |
Curie Temperature: |
-115°C |
Sureface: |
Bright,Oxided |
Delivery Time: |
7-50 Days |
Thermal Conductivity: |
11.5 W/m-K |
Melting Point: |
1385°C |
Elongation: |
30 % |
Nickel Alloy incoloy bar 800 Inconel 625 round bar Alloy pipe
The Inconel 718 nickel alloy, with outstanding fabricability, excellent weldability and long term structure stability, can be made into complex parts used for various industries. The nickel-chromium alloy has superb stress-corrosion cracking and pitting resistance at both high and low temperatures, and prominent resistance to high temperature oxidation.
The usability and economy with which Inconel alloy 718 can be fabricated, combined with great tensile, fatigue, creep and rupture strength as well as perfect resistance to radiation, oxidation and corrosion, has led to its use in a wide range of applications. Good case in point is components for aircraft turbine engines or other parts in oil, chemical and nuclear power industry.
Inconel 718 alloy is normally only used for component applications up to 1200°F (650°C); however, its oxidation resistance is comaparable to that for other gamma-prime-strengthened superalloys.
| Incoloy | Ni | Cr | Fe | C | Mn | S | Si | Cu | Al | Ti |
| 800H | 30.0-35.0 | 19.0-23.0 | 39.5min | 0.10max. | 1.50max. | 0.015max. | 1.0max. | 0.75max. | 0.15-0.60 | 0.15-0.60 |
Some typical applications are:
| AMS Number | Alloy | Type | UNS | Cross Ref. Spec | Misc./Shape | |
|---|---|---|---|---|---|---|
| AMS 5766 Bar | Incoloy 800H | Nickel | N08800 | - | Bar | |
| AMS 5766 Custom Tube | Incoloy 800H | Nickel | N08800 | - | Custom Tube | |
| AMS 5871 Plate | Incoloy 800H | Nickel | N08800 | - | Plate | |
| AMS 5871 Sheet | Incoloy 800H | Nickel | N08800 | - | Sheet | |
| AMS 5871 Strip | Incoloy 800H | Nickel | N08800 | - | Strip | |
contact us:
email:sales7@dlx-alloy.com
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Product Available Size:
Wires: Diameter0.5~7.5mm
Rods:Diameter8.0~200mm
Strip:Thickness0.5~2.5mm, Width5~180mm
Plate: Customized
Tube: Customized
