Product Details
Place of Origin: China Jiangsu
Brand Name: DLX
Certification: CE,ROHS
Model Number: Monel 400 strip
Payment & Shipping Terms
Minimum Order Quantity: 5
Packaging Details: Spool package with Carton box, Coil package with polybag for Monel 400 strip
Delivery Time: 5-20 Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500 tons per month
Material: |
Nickel Copper |
Nickel(Min): |
63% |
Curie Temperature: |
21-49℃ |
Density: |
8.05g/cm3 |
Application: |
Anti-corrosion |
Condition: |
Hard / Soft |
Sureface: |
Bright,Oxided |
Delivery Time: |
7-50 Days |
Melting Point: |
1288-1343℃ |
Name: |
Monel 400 Strip |
Material: |
Nickel Copper |
Nickel(Min): |
63% |
Curie Temperature: |
21-49℃ |
Density: |
8.05g/cm3 |
Application: |
Anti-corrosion |
Condition: |
Hard / Soft |
Sureface: |
Bright,Oxided |
Delivery Time: |
7-50 Days |
Melting Point: |
1288-1343℃ |
Name: |
Monel 400 Strip |
Monel 400 Characteristics
1;Resistant to seawater and steam at high temperatures
2;Excellent resistance to rapidly flowing brackish water or seawater
3;Excellent resistance to stress corrosion cracking in most freshwaters
4;Particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated
5;Offers some resistance to hydrochloric and sulfuric acids at modest temperatures and concentrations, but is seldom the material of choice for these acids
6;Excellent resistance to neutral and alkaline salt
7;Resistance to chloride induced stress corrosion cracking
8;Good mechanical properties from sub-zero temperatures up to 1020° F
9;High resistance to alkalis
Monel 400 Applications
1;Marine engineering
2;Chemical and hydrocarbon processing equipment
3;Gasoline and freshwater tanks
4;Crude petroleum stills
5;De-aerating heaters
6;Boiler feed water heaters and other heat exchangers
7;Valves, pumps, shafts, fittings, and fasteners
8;Industrial heat exchangers
9;Chlorinated solvents
10;Crude oil distillation towers
. Sour-gas service applications
. Oil and gas production safety lifts and valves
. Oil-well tools and instruments like drill collars
. Oil well industry
. Doctor blades and scrapers
. Chains, cables, springs, valve trim, fasteners for marine service
. Pump shafts and impellers in marine service
Typical Room Temperature Tensile Properties of Annealed Material
| Product Form | Condition | Tensile (ksi) | .2% Yield (ksi) | Elongation % | Hardness |
| Rod & Bar | Hot-Finished/Aged | 140-190 | 100-150 | 30-20 | 27-38 HRC |
| Rod & Bar | Hot Finished/Annealed | 90-110 | 40-60 | 45-25 | 75-90 HRB |
| Rod & Bar | Hot Finished/Annealed/Aged | 130-165 | 85-120 | 35-20 | 24-35 HRC |
| Rod & Bar | Cold-Drawn/Aged | 135-185 | 95-160 | 30-15 | 25-41 HRC |
| Rod & Bar | Cold-Drawn/Annealed/Aged | 130-190 | 85-120 | 30-20 | 24-35 HRC |
| Plate | ot-Finished/Aged | 140-180 | 100-135 | 30-20 | 27-37 HRC |
| Sheet | Cold-Rolled/Annealed | 90-105 | 40-65 | 45-25 | 85 HRB Max |
