Ni Fe Cr Material Incoloy 800 / 800H / 800HT Alloy Wire

Ni Fe Cr Material Incoloy 800 / 800H / 800HT Alloy Wire

Brand Name: DLX
Model Number: incoloy 800H
MOQ: 5
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Detail Information
Place of Origin:
China
Material:
Ni Fe Cr
Nickel(Min):
30%
Coefficient Of Expansion:
14.4 μm/m °C (20 – 100°C)
Specific Heat:
460 J/kg•°C
Density:
7.94 G/cm3
Curie Temperature:
-115°C
Condition:
Hard / Soft
Sureface:
Bright,Oxided
Delivery Time:
7-50 Days
Thermal Conductivity:
11.5 W/m-K
Melting Point:
1385°C
Elongation:
30 %
Packaging Details:
wooden case, woven polybag for incoloy 800 wire
Supply Ability:
300 tons per month
Highlight:

Incoloy 800 Alloy Wire

,

Incoloy 800H Alloy Wire

,

30% Ni Incoloy Alloy Wire

Product Description

Ni Fe Cr Material Incoloy 800 / 800H / 800HT Alloy Wire 0



Prime Quality Incoloy 800 / 800H / 800HT Alloy Wire Price Manufacturer


Ni Fe Cr Material Incoloy 800 / 800H / 800HT Alloy Wire 1


  • Inconel Series

Features: Incoloy 800 wire has a restricted carbon content range of 0.05 to 0.10%, which is in the upper portion of that of Incoloy 800, and is annealed at 1149 to 1177℃ (Incoloy 800 is annealed at 983 to 1038℃). These differences impart it to have higher stress rupture and creep properties than Incoloy 800.

Applications: Chemical and petrochemical process piping, high temperature heat exchangers, furnace components, carburizing equipment, heating-element sheathing, and nuclear power steam superheating tubing.




  • Chemical Properties of Incoloy 800H



Incoloy Ni Cr Fe C Mn S Si Cu Al Ti
800H 30.0-35.0 19.0-23.0 39.5min 0.10max. 1.50max. 0.015max. 1.0max. 0.75max. 0.15-0.60 0.15-0.60





  • Application


Some typical applications are:

  • Heat-treating equipment such as baskets, trays, and fixtures.
  • Chemical and petrochemical processing,
  • Heat exchangers and other piping systems in nitric acid media especially where resistance to chloride stress-corrosion cracking is required.
  • Nuclear power plants, it is used for steam-generator tubing.
  • Domestic appliances for sheathing of electric heating elements.
  • Production of paper pulp, digester-liquor heaters are often made of alloy 800.
  • Petroleum processing, the alloy is used for heat exchangers that air cool the process stream.






  • ,Type we could offer
    AMS Number Alloy Type UNS Cross Ref. Spec Misc./Shape
    AMS 5766 Bar Incoloy 800H Nickel N08810 - Bar Ni Fe Cr Material Incoloy 800 / 800H / 800HT Alloy Wire 2
    AMS 5766 Custom Tube Incoloy 800H Nickel N08810 - Custom Tube Ni Fe Cr Material Incoloy 800 / 800H / 800HT Alloy Wire 3
    AMS 5871 Plate Incoloy 800H Nickel N08810 - Plate Ni Fe Cr Material Incoloy 800 / 800H / 800HT Alloy Wire 4
    AMS 5871 Sheet Incoloy 800H Nickel N08810 - Sheet Ni Fe Cr Material Incoloy 800 / 800H / 800HT Alloy Wire 5
    AMS 5871 Strip Incoloy 800H Nickel N08810 - Strip Ni Fe Cr Material Incoloy 800 / 800H / 800HT Alloy Wire 6



Ni Fe Cr Material Incoloy 800 / 800H / 800HT Alloy Wire 7Ni Fe Cr Material Incoloy 800 / 800H / 800HT Alloy Wire 8Ni Fe Cr Material Incoloy 800 / 800H / 800HT Alloy Wire 9
