Product Details
Place of Origin: China
Brand Name: DLX
Model Number: 45CT
Payment & Shipping Terms
Minimum Order Quantity: 15
Packaging Details: Spool package with Carton box, Coil package with polybag
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Product Name: |
Thermal Spray Wire |
Grade: |
45CT |
Certificate: |
ISO9001 |
Material: |
Ni+Cr |
Application: |
Vacuum Coating |
Coating Hardness: |
30~35 HRC |
Bonding Strength: |
48.26 N/mm2 |
Size: |
0.8mm 1.2mm 1.6mm 2.4mm 3.2mm |
Name: |
TAFA 45 CT / Metco 8500 |
Surface: |
Brightly |
Product Name: |
Thermal Spray Wire |
Grade: |
45CT |
Certificate: |
ISO9001 |
Material: |
Ni+Cr |
Application: |
Vacuum Coating |
Coating Hardness: |
30~35 HRC |
Bonding Strength: |
48.26 N/mm2 |
Size: |
0.8mm 1.2mm 1.6mm 2.4mm 3.2mm |
Name: |
TAFA 45 CT / Metco 8500 |
Surface: |
Brightly |
3.2mm TAFA 45 CT Metco 8500 Thermal Spray Wire Rod For Combustion Furnace
1.Introduction:
DLX alloy offer nickel based thermal spray wire manufacturer in China. we could produce NiCrTi/45CT wire is a Nickel/Chrome/Titanium wire. 45CT wire is a nickel chromium titanium alloy characterized strong resistance to high temperature corrosion oxidation.
Typical applications for 45CT are widely used in combustion furnace,Boiler water wall tube, fan blade.
2.Typical Uses and Applications:
45CT material has proven very effective in providing long term protection to boiler tubes against high temperature sulfidation. The wrought material is highly resistant to sulfur/vanadium atmospheres up to 1800°F. Wrought material of this type has shown a 2 mil per year corrosion rate over a nine year period when used in the super heater section of boilers. Coatings of 45CT wire applied to boiler tubes have shown virtually no loss of thickness or spalling after 24 months of service (as of this writing).
| Item | Inconel 625 | Ni95Al5 | 45CT | Monel 400 | HC-276 | Cr20Ni80 | K500 |
| C | ≤0.05 | ≤0.02 | 0.01-0.1 | ≤0.04 | ≤0.02 | ≤0.08 | ≤0.25 |
| Mn | ≤0.4 | ≤0.2 | ≤0.2 | 2.5-3.5 | ≤1.0 | ≤0.06 | ≤1.5 |
| P | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.02 | ≤0.01 |
| S | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 |
| Si | ≤0.15 | ≤0.2 | ≤0.2 | ≤0.15 | ≤0.08 | 0.75-1.6 | ≤0.5 |
| Cr | 21.5-23 | ≤0.2 | 42-46 | - | 14.5-16 | 20-23 | - |
| Ni | Rest | Rest | Rest | 65-67 | Rest | Rest | Rest |
| Cu | - | - | - | Rest | - | - | 27-33 |
| Mo | 8.5-10 | - | - | - | 15-17 | - | - |
| Ti | ≤0.4 | 0.4-1 | 0.3-1.0 | 2.0-3.0 | - | - | 0.35-0.85 |
| Al | ≤0.4 | 4--5 | - | ≤0.5 | - | - | 2.3-3.15 |
| Fe | ≤1.0 | - | ≤0.5 | ≤1.0 | 4.0-7.0 | - | ≤1.0 |
| Nb | 3.5-4.15 | - | - | - | - | ≤1.0 | - |
| Co | - | - | - | - | - | - | - |
| V | - | - | - | - | ≤0.35 | - | - |
| W | - | - | - | - | 3.0-4.5 | - | - |
| Impurities | ≤0.50 | ≤0.50 | ≤0.50 | ≤0.50 | ≤0.50 | ≤0.50 | ≤0.50 |
The coatings of NW 450T wire is used to protect boiler tubes in thermal power plant such as water cooling tube, superheater tube, reheater tube and economizer tube from oxidation and sulfidation against high temperature.
It also proven to be particularly effective as a protective arc spray coating for boiler tubes in black liquor recovery boilers and coal fired utility boilers.
Wire: 0.8mm 1.2mm 1.6mm 2.4mm 3.2mm.
Products are generally supplied in standard cardboard boxes, pallets, wooden boxes. Special packaging requirements can also be accommodated. (also depend on the customers' requirements)
For the Thermal spray wires , we wind small size wire less than 1.6mm wires on spools. Bigger size over than 2.4mm in coils. Then put spools into cartons, Then put the cartons onto pallet or wood box.
1) Free sample could be supplied for testing purpose.
2) Customized lable, packing, OEM service.
3) Mill test certificate will be provided after production.
4) Good packing methods to keep goods statable.
| How can I contact with your company? |
| We are always ready to serve you via Email, Telephone, Fax, Skype, Whatsapp or Mobile |
| telephone. |
| What is your working time? |
| Monday-Saturday : 8:30AM-16:00PM (Beijing time, GMT+08.00) |
| We have public holiday during May.1-3, Oct.1-7 and Chinese New Year holiday . For detail, |
| please see our update holiday notice. During these period, if you have a demand, Please |
| send me an email. |
| Do you provide free samples? |
| Yes, we can provide a free sample for testing,buyer should bear all the shipping costs. |
| What is your payment terms? |
| T/T,L/C,D/A,D/P,Western Union,MoneyGram,Paypal |
| We are doing the best to match your demand. |
| What is the lead time? |
| Usually sample lead time is 7 days after payment has been confirmed. |
| Normal order is 10-30days,it depends on customers' quantity. |
| Anyway,we try to offer good-quality products as soon as possible. |
| Can you supply neutral packaging or labels with our company name? |
| Yes, please confirm on your requirements with your RFQ and order. Special packaging to individual requirements may also be available on request. |
