Product Details:

Place of Origin: China
Brand Name: DLX
Model Number: Monel 400

Payment & Shipping Terms:

Minimum Order Quantity: 5
Packaging Details: Spool package with Carton box, Coil package with polybag
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Get Best Price Contact Now

Detail Information

Material: Monel Nickel(Min): 63%
Curie Temperature: 21-49℃ Density: 8.05g/cm3
Application: Anti-corrosion Condition: Hard / Soft
Sureface: Bright,Oxided Delivery Time: 7-50 Days
Melting Point: 1288-1343℃ Name: Monel 400
High Light:

Monel 400 Material

,

Anti Corrosion Monel 400 Material

,

Oxided Monel 400 Plate

Product Description

Monel 400 Material Monel 400 Sheet Monel 400 Plate 0

Monel 400 Material Monel 400 Sheet Monel 400 plate


  • Monel SeriesMonel 400 Material Monel 400 Sheet Monel 400 Plate 1

Monel 400 plate is  produced and manufactured by dlx alloy with a wide range of Monel 400 plate size. It is a precipitation-hardenable nickel-copper alloy that combines the excellent corrosion resistance characteristic of Monel 400 with the added advantage of greater strength and hardness. These amplified properties, strength and hardness, are obtained by adding aluminum and titanium to the nickel-copper base and by a thermal processing used to effect precipitation, typically called age hardening or aging.

This nickel alloy is spark resistant and non-magnetic to -200° F. However, it is possible to develop a magnetic layer on the surface of the material during processing. Aluminum and copper may be selectively oxidized during heating, leaving a magnetic nickel rich film on the outside. Pickling orbright dipping in acid can remove this magnetic film and restore the non-magnetic properties.




  • Monel 400 Chemical Properties of Monel 400

Ni Cu C Mn Fe S Si
63.0-70.0 28-34 0.3 max

2

max

2.5 max 0.024 max 0.50 max


  • Monel 400 Application

. Sour-gas service applications
. Oil and gas production safety lifts and valves
. Oil-well tools and instruments like drill collars
. Oil well industry
. Doctor blades and scrapers
. Chains, cables, springs, valve trim, fasteners for marine service
. Pump shafts and impellers in marine service




  • Monel 400 Mechanical Properties

    Typical Room Temperature Tensile Properties of Annealed Material

    Product Form Condition Tensile (ksi) .2% Yield (ksi) Elongation % Hardness
    Rod & Bar Hot-Finished/Aged 140-190 100-150 30-20 27-38 HRC
    Rod & Bar Hot Finished/Annealed 90-110 40-60 45-25 75-90 HRB
    Rod & Bar Hot Finished/Annealed/Aged 130-165 85-120 35-20 24-35 HRC
    Rod & Bar Cold-Drawn/Aged 135-185 95-160 30-15 25-41 HRC
    Rod & Bar Cold-Drawn/Annealed/Aged 130-190 85-120 30-20 24-35 HRC
    Plate ot-Finished/Aged 140-180 100-135 30-20 27-37 HRC
    Sheet Cold-Rolled/Annealed 90-105 40-65 45-25 85 HRB Max





    Monel 400 Material Monel 400 Sheet Monel 400 Plate 2Monel 400 Material Monel 400 Sheet Monel 400 Plate 3
