Trays UNS N08810 Seamless Weld 800ht Incoloy Alloy

Name: Trays UNS N08810 Seamless Weld 800ht Incoloy Alloy
Brand: DLX
SKU: incoloy 800H
Rating: 4.6 (143 reviews)

Product Details

Place of Origin: China

Brand Name: DLX

Model Number: incoloy 800H

Payment & Shipping Terms

Minimum Order Quantity: 10

Packaging Details: wooden case, woven polybag

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          Trays Incoloy Alloy, UNS N08810 Nickel Base Alloy, 800ht Incoloy Alloy


Material:	Ni Fe Cr	Nickel(Min):	30%
Coefficient Of Expansion:	14.4 μm/m °C (20 – 100°C)	Specific Heat:	460 J/kg•°C
Density:	7.94 G/cm3	Curie Temperature:	-115°C
Sureface:	Bright,Oxided	Delivery Time:	7-50 Days
Thermal Conductivity:	11.5 W/m-K	Melting Point:	1385°C
Elongation:	30 %

Material:	Ni Fe Cr
Nickel(Min):	30%
Coefficient Of Expansion:	14.4 μm/m °C (20 – 100°C)
Specific Heat:	460 J/kg•°C
Density:	7.94 G/cm3
Curie Temperature:	-115°C
Sureface:	Bright,Oxided
Delivery Time:	7-50 Days
Thermal Conductivity:	11.5 W/m-K
Melting Point:	1385°C
Elongation:	30 %

Description

Trays UNS N08810 Seamless Weld 800ht Incoloy Alloy

Trays UNS N08810 Seamless Weld 800ht Incoloy Alloy 0

Trays UNS N08810 Seamless Weld 800ht Incoloy Alloy 1

Inconel Series

Common Trade Names: UNS N08810, Incoloy alloy 800H

Incoloy 800H semless weld pipe is an iron-nickel-chromium alloy having the same basic composition as Incoloy 800, with significantly higher creep rupture strength. The higher strength results from close control of carbon, aluminum and titanium contents in conjunction with a high temp anneal. The 800H modification was to control carbon (0.05 to 0.10%) and grain size to (>ASTM 5) to optimize stress rupture properties. Incoloy 800 H has further modifications to the combined titanium and aluminum levels (0.85 to 1.2%) to ensure optimum high temperature properties. The alloy is dual certified and combines the properties of both forms.

The chemical balance allows the alloy to exhibit excellent resistance to carburization, oxidation and nitriding atmospheres. 800HT will not become embrittled even after long periods of usage in the 1200-1600 deg F range where many stainless steels become brittle. Excellent cold forming characteristics typically associated with the nickel-chromium alloys are exhibited with 800HT. When cold formed extensively the grain size produces a visibly undulated surface called "orange peel". 800HT can be welded by the common techniques used on stainless steels.

Typical applications for the alloy include ethylene pyrolysis, hydrocarbon cracking, cracking furnaces for vinyl chloride, diphenol and acetic acid. The alloy is also used for valves, fittings and other components exposed to corrosive attack from 1100 to 1800 deg F.

Round bar ranging from 3/4" to 6" diameter, and light gauge sheet and plate. Incoloy 800 H material can be supplied in random lengths, cut to order or machined to customer requirements. Machining includes drilling, threading, milling, CNC shapes, turning, tapping, flanges and others.

Chemical Properties of Incoloy 800H

Incoloy	Ni	Cr	Fe	C	Mn	S	Si	Cu	Al	Ti
800H	30.0-35.0	19.0-23.0	39.5min	0.10max.	1.50max.	0.015max.	1.0max.	0.75max.	0.15-0.60	0.15-0.60

Application

Some typical applications are:

Heat-treating equipment such as baskets, trays, and fixtures.
Chemical and petrochemical processing,
Heat exchangers and other piping systems in nitric acid media especially where resistance to chloride stress-corrosion cracking is required.
Nuclear power plants, it is used for steam-generator tubing.
Domestic appliances for sheathing of electric heating elements.
Production of paper pulp, digester-liquor heaters are often made of alloy 800.
Petroleum processing, the alloy is used for heat exchangers that air cool the process stream.

,Type we could offer

AMS Number	Alloy	Type	UNS	Cross Ref. Spec	Misc./Shape
AMS 5766 Bar	Incoloy 800H	Nickel	N08800	-	Bar
AMS 5766 Custom Tube	Incoloy 800H	Nickel	N08800	-	Custom Tube
AMS 5871 Plate	Incoloy 800H	Nickel	N08800	-	Plate
AMS 5871 Sheet	Incoloy 800H	Nickel	N08800	-	Sheet
AMS 5871 Strip	Incoloy 800H	Nickel	N08800	-	Strip

Trays UNS N08810 Seamless Weld 800ht Incoloy Alloy 7
