Product Details:

Place of Origin: China
Brand Name: DLX
Model Number: incoloy 800H

Payment & Shipping Terms:

Minimum Order Quantity: 10
Packaging Details: wooden case, woven polybag
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Get Best Price Contact Now

Detail Information

Material: Ni Fe Cr Nickel(Min): 30%
Coefficient Of Expansion: 14.4 μm/m °C (20 – 100°C) Specific Heat: 460 J/kg•°C
Density: 7.94 G/cm3 Curie Temperature: -115°C
Sureface: Bright,Oxided Delivery Time: 7-50 Days
Thermal Conductivity: 11.5 W/m-K Melting Point: 1385°C
Elongation: 30 %
High Light:

UNS N88010 Iron Chromium Alloy

,

Incoloy Alloy800 Iron Chromium

,

AMS 5766 Iron Chromium Alloy

Product Description

Incoloy Alloy800 UNS N88010 AMS 5766 Iron Chromium Alloy 0


Incoloy Alloy800 UNS N88010 AMS 5766 Iron Chromium Alloy 1


  • Inconel Series

Common Trade Names: UNS N08810, Incoloy alloy 800H

INCOLOY alloy 800H is an alloy of nickel, iron and chromium. The alloy is capable of remaining stable and maintaining its austenitic structure even after long time exposures to high temperatures. Other characteristics of the alloy are good strength, and high resistance to oxidizing, reducing and aqueous environments. The standard forms in which this alloy is available are round, flats, forging stock, tube, plate, sheet, wire and strip.

800H is a nickel-iron-chromium alloy that is part of the family of 800 series of alloy. Also known as Nickel Alloy 800H, Incoloy 800H has many of the characteristics of the other 800 alloys. These include:

  • Resistance to prolonged exposure to elevated temperatures
  • Excellent resistance to oxidation, sulfidation, and carburization
  • Added Carbon and annealing treatment allows for higher creep and rupture properties above 1100°F (600°C)
  • Resistant to high temperature corrosion
  • Readily machined by standard methods
  • Best joined/welded using products for high temperature situations
  • Resistance to aqueous corrosion at moderate temperatures

  • Chemical Properties of Incoloy 800H



Incoloy Ni Cr Fe C Mn S Si Cu Al Ti
800H 30.0-35.0 19.0-23.0 39.5min 0.10max. 1.50max. 0.015max. 1.0max. 0.75max. 0.15-0.60 0.15-0.60












  • Application


Some typical applications are:

  • Heat-treating equipment such as baskets, trays, and fixtures.
  • Chemical and petrochemical processing,
  • Heat exchangers and other piping systems in nitric acid media especially where resistance to chloride stress-corrosion cracking is required.
  • Nuclear power plants, it is used for steam-generator tubing.
  • Domestic appliances for sheathing of electric heating elements.
  • Production of paper pulp, digester-liquor heaters are often made of alloy 800.
  • Petroleum processing, the alloy is used for heat exchangers that air cool the process stream.






  • ,Type we could offer
    AMS Number Alloy Type UNS Cross Ref. Spec Misc./Shape
    AMS 5766 Bar Incoloy 800H Nickel N08800 - Bar AMS 5766 Bar
    AMS 5766 Custom Tube Incoloy 800H Nickel N08800 - Custom Tube AMS 5766 Custom Tube
    AMS 5871 Plate Incoloy 800H Nickel N08800 - Plate AMS 5871 Plate
    AMS 5871 Sheet Incoloy 800H Nickel N08800 - Sheet AMS 5871 Sheet
    AMS 5871 Strip Incoloy 800H Nickel N08800 - Strip AMS 5871 Strip



Incoloy Alloy800 UNS N88010 AMS 5766 Iron Chromium Alloy 7Incoloy Alloy800 UNS N88010 AMS 5766 Iron Chromium Alloy 8Incoloy Alloy800 UNS N88010 AMS 5766 Iron Chromium Alloy 9
