Product Details:

Place of Origin: China
Brand Name: DLX
Model Number: Ni90Cr10

Payment & Shipping Terms:

Minimum Order Quantity: 5
Packaging Details: Spool package with Carton box, Coil package with polybag
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Get Best Price Contact Now

Detail Information

Material: Nickel, Chromium Nickel(Min): 89%
Resistivity: 0.78+/-0.05 Tensile Strength: 637MPA
Elongtation: ≥20% Application: Heating, Resistivity
Condition: Hard / Soft Sureface: Bright, Oxided, Acide
Delivery Time: 7-20 Days
High Light:

0.03mm Wire NiCr Alloy

,

637 MPA Nickel Chromium Heating Wire

,

Ni90Cr10 NiCr Alloy

Product Description

0.03mm Wire NiCr Alloy 0


0.03mm Wire NiCr Alloy 1


  • NiCr Series

Ni90Cr10 is an austenitic nickel-chromium alloy suitable for temperature applications up to 1250°C. High chromium content (30% in average) provides very good life time, especially in the furnace applications, it is most used in vape, as a heating element.

Ni90Cr10 is characterized by high resistivity, good oxidation resistance, good ductility after use and excellent weldability. Alloy is not subject to “green rot” and is particularly well suited for reducing and oxidizing atmospheres.

Ni70Cr30 is used for electric heating elements in industrial furnaces. Typical applications are: electric and enamelling furnaces, storage heaters, furnaces and kilns with a changing atmospheres.


















  • Nickel-chromium alloy performance tables
Performance material Cr10Ni90 Cr20Ni80 Cr30Ni70 Cr15Ni60 Cr20Ni35 Cr20Ni30
Composition Ni 90 Rest Rest 55.061.0 34.037.0 30.034.0
Cr 10 20.023.0 28.031.0 15.018.0 18.021.0 18.021.0
Fe   ≤1.0 ≤1.0 Rest Rest Rest
Maximum temperature 1300 1200 1250 1150 1100 1100
Meltiing point 1400 1400 1380 1390 1390 1390
Density g/cm3 8.7 8.4 8.1 8.2 7.9 7.9
Resistivity   1.09±0.05 1.18±0.05 1.12±0.05 1.00±0.05 1.04±0.05
μΩ·m,20
Elongation at rupture ≥20 ≥20 ≥20 ≥20 ≥20 ≥20
Specific heat   0.44 0.461 0.494 0.5 0.5
J/g.
Thermal conductivity   60.3 45.2 45.2 43.8 43.8
KJ/m.h
Coefficient of lines expansion   18 17 17 19 19
a×10-6/
(201000℃)
Micrographic structure   Austenite Austenite Austenite Austenite Austenite
Magnetic properties   Nonmagnetic Nonmagnetic Nonmagnetic Weak magnetic Weak magnetic




  • The Form we could offer
Size Range

Wire
dia 0.03-7.5mm
0.03mm Wire NiCr Alloy 2
dia 8.0-12.0mm
0.03mm Wire NiCr Alloy 3
Ribbon
(0.05-0.35)*(0.5-6.0)mm
0.03mm Wire NiCr Alloy 4
Strip
(0.50-2.5)*(5-180)mm
0.03mm Wire NiCr Alloy 5
Rod
8-50mm

0.03mm Wire NiCr Alloy 6
