Incoloy 800ht N08811 AMS 5766 Aluminum Chromium Alloy

Incoloy 800ht N08811 AMS 5766 Aluminum Chromium Alloy

Product Details:

Place of Origin: China
Brand Name: DLX
Model Number: incoloy 800

Payment & Shipping Terms:

Minimum Order Quantity: 5
Packaging Details: Spool package with Carton box, Coil package with polybag
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Get Best Price Contact Now

Detail Information

Material: Ni Fe Cr Nickel(Min): 30%
Coefficient Of Expansion: 14.4 μm/m °C (20 – 100°C) Specific Heat: 460 J/kg•°C
Density: 7.94 G/cm3 Curie Temperature: -115°C
Condition: Hard / Soft Sureface: Bright,Oxided
Delivery Time: 7-50 Days Thermal Conductivity: 11.5 W/m-K
Melting Point: 1385°C Elongation: 30 %
High Light:

Incoloy 800ht Aluminum Chromium Alloy

,

N08811 Chromium Aluminum Alloy

,

AMS 5766 Aluminum Chromium Alloy

Product Description

Incoloy 800ht N08811 AMS 5766 Aluminum Chromium Alloy 0


Incoloy 800ht N08811 AMS 5766 Aluminum Chromium Alloy 1


  • Inconel Series

Common Trade Names: Incoloy 800, Alloy 800, Ferrochronin 800, Nickelvac 800, Nicrofer 3220.

INCOLOY 800 (UNS N08800, W. Nr. 1.4876) is a widely used material for construction of equipment requiring corrosion resistance, heat resistance, strength, and stability for service up to 1500°F (816°C). Alloy 800 offers general corrosion resistance to many aqueous media and, by virtue of its content of nickel, resists stress corrosion cracking. At elevated temperatures it offers resistance to oxidation, carburization, and sulfidation along with rupture and creep strength. For applications requiring greater resistance to stress rupture and creep, especially at temperatures above 1500°F (816°C), INCOLOY alloys 800H and 800HT are used.






  • Chemical Properties of Incoloy 800



Incoloy Ni Cr Fe C Mn S Si Cu Al Ti
800 30.0-35.0 19.0-23.0 39.5min 0.10max. 1.50max. 0.015max. 1.0max. 0.75max. 0.15-0.60 0.15-0.60



  • Application


Some typical applications are:

  • Heat-treating equipment such as baskets, trays, and fixtures.
  • Chemical and petrochemical processing,
  • Heat exchangers and other piping systems in nitric acid media especially where resistance to chloride stress-corrosion cracking is required.
  • Nuclear power plants, it is used for steam-generator tubing.
  • Domestic appliances for sheathing of electric heating elements.
  • Production of paper pulp, digester-liquor heaters are often made of alloy 800.
  • Petroleum processing, the alloy is used for heat exchangers that air cool the process stream.






  • ,Type we could offer
    AMS Number Alloy Type UNS Cross Ref. Spec Misc./Shape
    AMS 5766 Bar Incoloy 800 Nickel N08800 - Bar AMS 5766 Bar
    AMS 5766 Custom Tube Incoloy 800 Nickel N08800 - Custom Tube AMS 5766 Custom Tube
    AMS 5871 Plate Incoloy 800 Nickel N08800 - Plate AMS 5871 Plate
    AMS 5871 Sheet Incoloy 800 Nickel N08800 - Sheet AMS 5871 Sheet
    AMS 5871 Strip Incoloy 800 Nickel N08800 - Strip AMS 5871 Strip
