Product Details
Place of Origin: China
Brand Name: DLX
Model Number: Inconel 617
Payment & Shipping Terms
Minimum Order Quantity: 5
Packaging Details: Spool package with Carton box, Coil package with polybag
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Material: |
Ni, Cr, Co, Mn |
Nickel(Min): |
44.5% |
Specific Heat: |
419 J/kg-°C |
Electrical Resistivity 26°C: |
1.22 µΩ-m . |
Density: |
8.36 G/cm3 |
Condition: |
Hard / Soft |
Sureface: |
Bright,Oxided |
Delivery Time: |
7-50 Days |
Melting Range: |
1332-1380 ℃ |
Material: |
Ni, Cr, Co, Mn |
Nickel(Min): |
44.5% |
Specific Heat: |
419 J/kg-°C |
Electrical Resistivity 26°C: |
1.22 µΩ-m . |
Density: |
8.36 G/cm3 |
Condition: |
Hard / Soft |
Sureface: |
Bright,Oxided |
Delivery Time: |
7-50 Days |
Melting Range: |
1332-1380 ℃ |
Nickel Inconel 617 is a solid-solution, nickel-chromium-cobalt-molydenum alloy with an exceptional combination of high-temperature strength and oxidation resistance. The alloy also has excellent resistance to a wide range of corrosive environment, and it is readily formed and welded by conventional techniques.
The high nickel and chromium contents make the alloy resistant to a variety of both reducing and oxidizing media. The aluminum, in conjunction with the chromium, provides oxidation resistance at high temperatures. Solid-solution strengthening is imparted by the cobalt and molydenum.
UNS Designation | Inconel Alloy | Nickel | Cromium | Cobalt | Molybdenum | Aluminium | Carbon | Iron | Manganese | Silicon | Sulfur | Titanium | Copper | Boron |
N06617 | 617 | 44.5 min. | 20.0 - 24.0 | 10.00 - 15.00 | 8.0 -10.0 | 0.8-1.5 | 0.05 -0.15 | 3.0max | 1.0 max. | 3.0max | 0.015 max. | 0.6 max | 0.5 max. | 0.006max |
The combination of high strength and oxidation resistance at temperatures over 1800°F makes alloy 617 an attractive material for such components as ducting, combustion cans, and transition liner in both aircraft, and land based gas turbines. Because of its resistance to high-temperature corrosion, the alloy is used for catalyst-grid supports in the production of nitric acid, for heat-treating baskets, and for reduction boats in the refining of molybdenum. Alloy 617 also offers attractive properties for components of power-generating plants, both fossil-fueled and nuclear
AMS Number | Alloy | Type | UNS | Cross Ref. Spec | Misc./Shape | |
---|---|---|---|---|---|---|
AMS 5887 Bar | Inconel 617 | Nickel | N06617 | - | Bar | ![]() |
AMS 5887 Custom Tube | Inconel 617 | Nickel | N06617 | - | Custom Tube | ![]() |
AMS 5887 Forging | Inconel 617 | Nickel | N06617 | - | Forging | ![]() |
AMS 5887 Ring | Inconel 617 | Nickel | N06617 | - | Ring | ![]() |
AMS 5888 | Inconel 617 | Nickel | N06617 | - | Plate | ![]() |
AMS 5889 Sheet | Inconel 617 | Nickel | N06617 | - | Sheet | ![]() |
AMS 5889 Strip | Inconel 617 | Nickel | N06617 | - | Strip | ![]() |
